LCD SPLICING SCREEN WITH LARGE SIZE

AND NARROW EDGE


Large size narrow edge LCD splicing screen can be used as a display alone, and can be spliced into a large screen.According to the different using requirements, achieve the function of variable will be small changed time, cooperate with the emperor cloud system, which can realize network echo, high-definition picture display, image reproduction arbitrary scaling and stretching, any open the window and roaming IP networks, local plan adjustment, decoding, signal superposition of a key word search, input channel, and other functions.Its representative size is 60 inches.


DIVERSITY INTERFACE

The whole machine has HDMI, VGA, USB, RS232 and other professional interfaces.


HIGH QUALITY LCD PANEL

Strict selection of imported original LCD panel, to ensure that the use at ease.Strict selection of imported original LCD panel, to ensure that the use at ease.

FUNCTION


MULTISIGNAL PROCESSING PERFORMANCE

It has the ability to detect and recognize various video signals automatically and can process many kinds of signals

IMAGE QUALITY IS CLEAR

Quality using the latest 3 d digital processing circuit, Full HD 1080 p resolution, according to a broad perspective, brightness 500 lumens, image under strong ambient light bright and clear, gorgeous soft Full screen equilibrium under dark ambient light brightness, 100% of the color temperature adjustment, high contrast, high-definition picture perfect display, LED backlight color reduction degree is higher, graphics automatically set and adjusted automatically


ENERGY CONSERVATION AND BACKLIGHT

Low power consumption, energy saving and environmental protection, no radiation, automatic standby function without signal, automatic adjustment of local backlight, 35% power saving screen protection function, effectively extend product service life of LCD screen up to more than 50,000 hours, can support 7*24h uninterrupted work


RELIABILITY DESIGN

The whole machine is safe and durable, the equipment is not afraid of scratch, dust, oil, anti - electromagnetic interference, anti - light interference


SPECIFICATIONS

LDW-9A5L60A/ LDW-9A7L60A

SIZE AND WEIGHT:

60 inches

Length: 1367mm (53.82 in.)

Height: 755mm (29.72 in.)

Thickness: 96mm (3.78 in.)

Net weight: 26kg (57.32 LBS)


PRODUCT AND LCD PANEL MODEL:

LDW-9A5L60A/DC-600F
L600FB1-1

LDW-9A7L60A/DC-600FA
L600FB1-2

COLOR, BRIGHTNESS AND CONTRAST:

8BIT,16.7M
500cd/m2
2400:1

8BIT,16.7M
700cd/m2
2400:1

DOUBLE SIDE SPLIT SEAM AND POWER:

Upper and lower seam 6.5mm;Left and right seam 6.5mm

300W (full load working condition)

Upper and lower seam 6.5mm;Left and right seam 6.5mm

300 w.

DYNAMIC CONTRAST:

7000:1

RESPONSE TIME:

6ms

BACK LIGHT:

LED

VIEWING ANGLE:

176/176 degrees

POWER SUPPLY REQUIREMENTS:

AC 110V@60HZ / 220V@50HZ

VESA DPMS

STANDBY POWER CONSUMPTION:

0.5W

SERVICE LIFE:

More than 50,000 hours

MAXIMUM RESOLUTION SUPPORTED:

13660*768
